Introduction

Philip's Navigator data set provides a particularly cost effective raster coverage of the road network of Great Britain at a uniform scale of 1:100,000.

© Copyright George Philip

Based on Ordnance Survey 1:50,000 mapping, it is tied to the National Grid and contains not only highly accurate and detailed road data (including roundabouts, motorway junctions and minor lanes and tracks) but also a considerable depth of named geographic features such as small settlements and farms, woodlands, rivers and lakes.

The raster dataset consists of 156 individual tiles, each representing a double page of the printed atlas. Each tile has been scanned at a resolution of 200 dots per inch (dpi) and edgematched with adjoining tiles to create a seamless dataset of the whole of Great Britain.

George Philip Navigator 1:100,000 scale mapping

Product	Cost	Update cost
George Philip Navigator 1:100,000 scale mapping (GB)	Ł7,500.00	Ł1,500.00 renewal fee at end of year 2
George Philip Navigator 1:100,000 scale mapping (England)	Ł4,999.00	Ł999.80 renewal fee at end of year 2
George Philip Navigator 1:100,000 scale mapping (Scotland)	Ł2,499.00	Ł499.80 renewal fee at end of year 2
George Philip Navigator 1:100,000 scale mapping (Wales)	Ł1,299.00	Ł259.80 renewal fee at end of year 2
George Philip Navigator 1:100,000 scale mapping (1 region)	Ł699.00 per region	Ł139.80 renewal fee per region at end of year 2
George Philip Navigator 1:100,000 scale mapping (2-5 regions)	Ł660.00 per region	Ł132.00 renewal fee per region at end of year 2
George Philip Navigator 1:100,000 scale mapping (6-12 regions)	Ł630.00 per region	Ł126.00 renewal fee per region at end of year 2

George Philip Navigator 1:100,000 scale raster data is available for Great Britain, England, Scotland and Wales.

Regional subsets are also available:

South West England
South Central England
South East England
South and Mid Wales
Midlands
East Anglia
North Wales and West Lancashire
Yorkshire and East Lancashire
North East England and South East Scotland
South West Scotland
North West Scotland
North East Scotland

Payment of the data supply charge entitles the licensee to access and manipulate the data for a period of two years from the date of supply for internal business use only, and to print from the data a maximum of 5,000 hard copies for a standard licence or 10,000 hard copies for a multi-user licence.

At the end of the two year licence period, a renewal charge of 20% of the initial supply charge will be payable for use of the data on the same terms and conditions for a further two years.

Licensees choosing not to renew their licence will be asked to confirm in writing that they have deleted from their computer systems, including archives and backups, all the data supplied under the Agreement.
